TOW-BEHIND GENERATOR 70 kVA

These super-silent portable generators provide reliable power to meet the most demanding requirements. They are designed and built to withstand tough environments at construction sites and provide dependable temporary power at entertainment venues and disaster recovery operations.

Power Output: Prime 70kVA (56 kW), StandBy 77kVA (62 kW)

Voltage/Frequency - 3 Phase: 208, 220, 240, 416, 440, 460, 480 Switchable 60Hz

Voltage/Frequency - 1 Phase: 120, 127, 139, 240, 254, 277 Switchable 60Hz

Max. Amperage Single Phase: 120 Volt - 155 Amps 4-Wire, 168 Amps Zigzag

Max. Amperage Single Phase: 240 Volt - 79 Amps 4-Wire, 168 Amps Zigzag

Max. Amperage 3 Phase: 240 Volt - 168 Amps, 480 Volt - 84 Amps

Noise Level: 65 dBa At Full Load and 23 Feet Away

Power: 4 Cyl, 95.2 Hp, 2.99L, Epa Tier 4F Engine

Fuel Type and Capacity: Diesel, 103 Gals. - Def, 7.4 Gals.

Average Fuel Consumption: Full Load At 4.4 Gph, 1/2 Load At 2.6 Gph, 1/4 Load At 1.7 Gph

Tire Size: ST205/75D15 (4 Each - Tandem Axle)

Operating Weight: 6,285 Lbs.

Overall Size (LxWxH): 14 Ft. 2 In. x 73 In. x 95 In.
